Loading Dock Seals - 14 In Projection 8 x 9 Door, Vestil

Part# VES-D-350-14
Ships Within 48-72 Hours
Ships by Truck
  • The superior nylon reinforced vinyl facing has a higher tear strength than equivalent weight hypalon. The chemically sealed ends prevent moisture infiltration. It is mounted on and bonded on a durable wolmanized wood and contains a full height air escape tunnel. The unit consists of a three (3) piece construction with beveled sides and a through the wall installation kit that is included. Five (5") maximum compression is recommended. Application with a flush dock to building in conjunction with an Edge-O-Dock use a twenty (20) inch projection Dock Seal. To ensure proper size complete the survey sheet. This unit is non-returnable.
  • Projection (in.): 14
  • Nylon Reinforced Vinyl (oz.): 36
  • Nylon Reinforced Guide Strips (in.): 2
  • Top Pad Flap Height (in.): 12
  • Side Wall Width (in.): 9-1/2
  • Face Width (in.): 12
  • Maximum Compression (in.): 5
  • Side Height (in.): 108
  • Max Door Width (in.): 96
  • Max Door Height (in.): 108
  • Product Length (in.): 14
  • Product Width (in.): 120
  • Product Height (in.): 120
