Single Stage Regulators, Inert Gases, CGA 580, 4,000 psi inlet - Gentec 452IN-300
- Chrome plated housing cap
- Self re-seating external pressure relief valve on oxygen, inert gas, CO2 and nitrogen models
- Sintered bronze inlet filter
- Stem type seat assembly for more reliable performance
- The "Horse" is a Harris® style regulator with a Victor® style seat mechanism
- Underwriters Laboratories Inc. listed
More v
- Applications: Welding; Heating; Cutting
- Body Material: Forged Brass
- Diaphragm Size: 2 3/4 in
- Inlet Pressure [Max]: 4,000 psi
- Gas Type: Inert Gases
- Gauge Size: 2 in
- Outlet Pressure [Max]: 400 psi
- Inlet Connection: CGA 580
- Outlet Connection: 5/8 in - 18 RH(F)
- Type: Regulator
- Wt.: 3 lb
- Country of Origin: CN
WARNING: This product contains a chemical known to the State of California to cause cancer. For more information, go to www.P65Warnings.ca.gov.
