Gearwrench 84121 1/4" Drive 6 Point Standard Impact Socket 12mm | 84121
- Chrome Molybdenum Alloy Steel (Cr-Mo) for Exceptional Strength and Durability
- Surface Drive Technology Reduces Fastener Rounding
- Manganese Phosphate Coating to Resist Corrosion
- High Visibility Laser Etched Markings
- Secondary Hard Stamping
- Meets or Exceeds ASME B107.33M
More v
- Description: 1/4" Drive 6 Point Standard Impact Socket 12mm
- ASME Specification: B107.33M
- Dim. A: Drive End: 0.512 in
- Dim. B: Wrench End: 0.669 in
- Dim. C: Overall Length: 0.906 in
- Dim. D: Bolt Clearance: 0.327 in
- Dim. E: Wrench Depth: 0.240 in
- Dim. F: Length to Shoulder: 0.905 in
- Drive Tang Size: 1/4 in
- Drive Type: 6 Point
- Fastener Size: 12 mm
- Length Format: Standard
- Packaging: Carded
- Product Name: Impact Socket
- SAE/Metric/Torx: Metric
- UNSPSC_V7.0901: Sockets
- UPC: 099575841217
- Weight: 0.07 lb
WARNING: This product contains a chemical known to the State of California to cause cancer. For more information, go to www.P65Warnings.ca.gov.
