Dixon Valve 16HTF16 2 Iso16028 Coup | 2 F-NPTF Steel
- Hex: 2-1/2"
- Interchange: Flush Face
- Length: 6.75"
- Maximum OD: 3.95"
- Pipe Thread: NPT / NPTF
- Pressure Rating: See Product Details
- Product Material: Steel
- Series: DQC HT-Series
- Thread: Female NPTF
- Thread Size: 2" 11-1/2
- Specifications: Rated pressure for connected Steel Coupler and Steel Plug 3,000 PSI 207 bar Maximum Working and 12,000 PSI 828 bar burstRated pressure for uncoupled Steel Coupler 3,000 PSI 207 bar Maximum Working and 12,000 PSI 828 bar burst
- Features: High flow performance compact profileEasily rebuildable!DORS dual opposing retention spheres retention system prevents valve stem ejection during surge flow and pressure spike conditions.
- Compatibility & Interchange Data: Compatibility amp Interchange Data Interchangeable to ISO16028Conforms to ISO16028 interchange standard interchangeable with Eaton/Hansen FF Parker FEM Snap-tite 74 Faster FFH/2FFN/2FFI Stucchi A/FIRG and Holmbury HQ/A/FIMC
