Jacobs Chuck 9751 J422 Rubber Flex Tap Collet
- Parallel Jaw Insert Surfaces Exert Uniform, Accurate Gripping Force Up to Three Times Greater Than Can Be Achieved with Split-Steel Collets.
- Each Collet Accepts and Precisely Centers A Wide Range of Both Decimal or Metric Diameters (Within Individual Capacity Ranges) to Speed Setups and Increase Machining Productivity.
- Durable One-Piece Construction. Synthetic Rubber Retains Flexibility and Resists Deterioration From Heat, Coolants and Cutting Compounds.
- Steel Jaw Inserts Precision Ground After Molding Process to Ensure Maximum Gripping Accuracy. Hardened for Greater Wear Resistance Than Split Steel Collets.
- Each Collet Bore is Held Concentric to the O.D. Tapers, Front and Back, to Minimize T.I.R.
- Automatically Seals Tool O.D. to Prevent Coolant Flow Through Thus Increasing Tool Wear.
- Seals Collets and Machine Spindles to Protect From Abrasive Particles and Swarf.
More v
- Catalog Number: 9751
- Cone Angle: 40
- Contact Length: 0.500 in
- Coupon Headline: Tap Chuck Collets
- Long Description: J422 Rubber Flex Tap Collet
- Maximum Capacity: 0.383 in
- Minimum Capacity: 0.253 in
- Model Number: J422
- Number of Inserts: 6
- Outside Diameter: 0.941 in
- Packaging: Boxed
- Shelf Pack Qty.: 1
- Table Description: J422 Rubber Flex Tap Collet
- UNSPSC_V7.0901: Collets
- UPC: 095456097513
- Weight (Catalog): 0.70 lb
